DDG-99B Conductivity Transmitter丨Intelligent Online丨Boiler water surface water

Product Feature

16-bit high-precision A/D and high-performance microprocessor technology, capable of conducting conductivity and temperature test, temperature compensation, instrument self-checking and other functions
Graphic dot matrix liquid crystal, with LED backlighting, with a protective case that can operate under direct sunlight exposure.
The range can be automatically switched, and the range of the output signal can be set arbitrarily within the full range.
Automatic temperature compensation. Select the measured water quality according to different working conditions. Store multiple compensation curves in memory. Press the buttons to correct the temperature compensation coefficient and click the constant.
Automatically adjust the measurement frequency to avoid electrode polarization and improve measurement accuracy

The DDG-99B series conductivity transmitter is a four-wire, single-channel transmitter independently developed by Dongrun Instruments. The transmitter offers more signal output and control functions, making operation more convenient. It is compatible with Dongrun as well as commonly used contact-type two-electrode conductivity sensors in the market.

Get A Free Quote

Products Categories

Level Measurement

Magnetic Level Gauge

Magnetostrictive Level Gauge

Radar Level Gauge

Static Pressure Type Level Guage

Ultrasonic Level Meter

Level Switch

Online Water Sensors & Transmitters

Cast Aluminum Housing Explosion-Proof Transmitter

Wall-Mounted Transmitter

Disc-Mounted Transmitters

Multi-Parameter Transmitter

pH/ORP

Conductivity/ACID, Alkali and Salt Concentration Meter

Turbidity / Suspended Matter / Sludge Concentration

Dissolved Oxygen by Fluorescence Method

UV254

Nitrate Sensor

Disinfectant (Residual Chlorine) Sensor

Drinking Water Multi-Parameter Detector

Cleaning Sheath and Installation Accessories

Multi-parameter water testing kit (Portable)

Online Water Analyzers

Nutrients and Organic Substances

Inorganic Ions

Heavy Metals

Industrial Process Water Analysis System

Water Analysis Shelter

Water Quality Monitoring Station

Buoy-Based Water Quality Monitoring Station

Product Features

Excellent Environmental Adaptability:

IP65 protection rating certification, PC material housing, robust casing, and good weather resistance.
Temperature range: -20°C to 60°C, suitable for more application scenarios.

Intelligent Instrument:

The transmitter can output 2 channels of 4-20mA, 3 customizable relays, and 1 RS485 communication port.
Universal transmitter with a high-definition LCD screen, displaying more instrument information on a single screen, with Chinese and English menus.
Four-wire intelligent instrument, HART 7.5 communication protocol allows transmission of more instrument status information (official member of the HART Communication Foundation).
Calibration and parameter setting via 7 buttons, making operation simple and convenient.
Multi-level password protection ensures reliable and secure measurement data.
Automatic temperature compensation, with PT100/PT1000 temperature sensors manually selectable.
Two-point calibration, automatic standardsolution recognition.

Application Areas

It is widely used in industrial reaction processes, water treatment, circulating water, wastewater, boiler water, environmental protection, and other application environments.

Application Scenarios

Surface water, boiler water, drinking water, food, beverages, chemical industry, biopharmaceuticals, online monitoring of conductivity in reverse osmosis/pure water production processes

Product Feature

16-bit high-precision A/D and high-performance microprocessor technology, capable of conducting conductivity and temperature test, temperature compensation, instrument self-checking and other functions
Graphic dot matrix liquid crystal, with LED backlighting, with a protective case that can operate under direct sunlight exposure.
The range can be automatically switched, and the range of the output signal can be set arbitrarily within the full range.
Automatic temperature compensation. Select the measured water quality according to different working conditions. Store multiple compensation curves in memory. Press the buttons to correct the temperature compensation coefficient and click the constant.
Automatically adjust the measurement frequency to avoid electrode polarization and improve measurement accuracy
