Digital type Model:DRCM-99I
Capable of measuring and outputting multiple parameters, including level, interface level, five-point temperature, and average temperature.
Standard Modbus/RTU protocol for long-distance transmission with excellent anti-interference performance.
Simple system wiring, enabling direct communication with computers, display controllers, or industrial control systems, allowing real-time data collection, display, alarm, and monitoring for multiple sensors.
Compatible with both soft cable and rigid rod; maximum length: 6m for rigid rod, 20m for soft cable.
Explosion-proof design: Intrinsically safe Exia IICT6 or flameproof Exd IICT6, ensuring safe use in various hazardous and explosive environments.
Product Parameters
- Measurement Parameters: Level + Interface Level + 1–5 Temperature Points (MODBUS Protocol/RS485)
- Level Measuring Range: 200mm–20m
- Level Accuracy: 0.1% F.S. or 0.5mm
- Temperature Measuring Range: -20℃ to 100℃
- Temperature Accuracy: ±0.25℃
- Power Supply Voltage: 12–32VDC
- Medium Temperature: -40℃ to 100℃ (higher temperatures available upon request)
- Interface Type: RS-485 (Modbus)
- On-site Display: Optional LCD display
- Protection Rating: IP65/IP66
- Explosion-proof Rating: Exia IICT6Ga/Exd IICT6Gb
- Electronic Housing Material: Cast aluminum or stainless steel housing
- Protection Tube Material: 304/316L stainless steel / 304 fluorine-lined
Installation Method: Threaded or flanged
Application Scenarios
Ideal for fuel storage tanks, tank farms, and multi-parameter monitoring applications.
